Aluminium Box Profile
Aluminium Box Profiles
Square hollow aluminium sections for structural framing, glazing support and architectural construction
Square hollow aluminium — the "box" section — combines torsional rigidity, straight clean lines, and the full weight advantages of the 6063 extrusion family. It is the default specification for façade framing, glazing mullions, partition substructure, railings, and volume architectural fabrication.
Aluprofilium extrudes aluminium box profiles across the full range of square cross-sections in T5 and T6 tempers, with mill, anodized, brushed, and powder-coated finishes. Large-volume project orders, custom lengths, and full RAL color matching are handled as standard for distributor and contractor clients.
Technical overview
Current product information
- Material
- Aluminium extrusion, 6063 alloy (T5/T6 tempers)
- Standard cross-sections
- 15x15, 20x20, 25x25, 30x30, 40x40, 50x50, 60x60 mm
- Wall thickness
- 1.5, 2.0, 2.5, 3.0 mm
- Standard length
- 6 m (cut-to-size available)
- Finishes
- Mill, anodized, brushed, powder-coated (full RAL)
- Packaging
- Bulk bundled, film-wrapped, export-ready
Technical guidance
Prepare a clearer profile requirement.
Use the specification and finish guides to organise the available drawing, dimensions, surface direction and commercial inputs.
Selected for Aluminium Box ProfilesSurface finish
Finish direction
Surface options are reviewed against the selected profile, intended use and quotation requirements.
Review finish optionsExport preparation
Packaging context
Protective wrapping, bundling, cartons or crates are selected according to the profile and shipment requirement.
Review packaging & exportTechnical file
Catalog & specification
Use the current catalog as a reference, then confirm the selected section and technical requirement with the export desk.
Open product catalog Request technical information
